LL28H LED Linear Light
Minimalistic and Uniform Light
Media Facade Application
■ Minimalistic appearance design
■ The outdoor self-cleaning design ensures greater performance and higher reliability.
■ High-strength aviation aluminum housing.
■ Weathering and UV resistant PC diffuser.
■ Optical dark-free zone design for seamless splicing of uniform light.
■ International standard DMX512 protocol.
| Wattage | 12W | 12W | 15W |
|---|---|---|---|
| Color Temperature | White | RGB | RGBW |
| Luminous Flux | 720 lm @4000K | ||
| Beam Angle (50%Imax) | 130° | ||
| LED Brand | CREE / NICHIA / OSRAM / LUMILEDS | ||
| Input Voltage | DC24V | ||
| Protection Class IEC | III | ||
| Control | DMX / ON-OFF | DMX | DMX |
| Finish | Powder coating | ||
| Housing | Extruded aluminum 6063 | ||
| Cover | High strength optical PC | ||
| IP Rating | IP65 | ||
| IK Rating | IK10 | ||
| Mounting | Buckle | ||
| Operation Temperature | -35°C ~ 60°C (-31°F ~ 140°F) | ||
| Storage Temperature | -40°C ~ 70°C (-40°F ~ 158°F) | ||
| Lifespan | >50,000Hrs (Ta=35°C@L70) | ||
| Certificate | CE / RoHS | ||
■ Please contact our sales team for more product details.
■ Archillumi work on global lighting market. Products can be customized based on special requirement.
