PL4840 LED Pixel Light
Minimalistic and High brightness
Media Facade Application
■ Small and skillful design
■ The outdoor self-cleaning design ensures greater performance and higher reliability.
■ Weathering and fireproof PC housing
■ Intelligent stepless dimming technology adopted.
■ High brightness contrast
■ International standard DMX512 protocol.
Wattage | 2.5W | 2.5W | 3W |
---|---|---|---|
Color Temperature | White | RGB | RGBW |
Luminous Flux | 187lm @4000K | ||
Beam Angle (50%Imax) | 110° | ||
LED Brand | CREE / NICHIA / OSRAM / LUMILEDS / EPISTAR | ||
Input Voltage | DC24V/DC48V | ||
Protection Class IEC | III | ||
Control | DMX / ON-OFF | DMX | DMX |
Finish | Rough black | ||
Housing | High strength engineering PC | ||
Cover | High strength optical PC | ||
IP Rating | IP65 | ||
IK Rating | IK10 | ||
Mounting | Buckcle | ||
Operation Temperature | -35°C ~ 60°C (-31°F ~ 140°F) | ||
Storage Temperature | -40°C ~ 70°C (-40°F ~ 158°F) | ||
Lifespan | >50,000Hrs (Ta=35°C@L70) | ||
Certificate | CE / RoHS / EMC |
■ Please contact our sales team for more product details.
■ Archillumi work on global lighting market. Products can be customized based on special requirement.
