PL35 LED Pixel Light

Minimalistic and High brightness
Media Facade Application

■ Small and skillful design
■ The outdoor self-cleaning design ensures greater performance and higher reliability.
■ Weathering and fireproof PC housing
■ Intelligent stepless dimming technology adopted.
■ High brightness contrast
■ International standard DMX512 protocol.

Wattage 1W 1W 1.5W
Color Temperature White RGB RGBW
Luminous Flux  75lm @4000K
Beam Angle (50%Imax) 110°
LED Brand CREE / NICHIA / OSRAM / LUMILEDS / EPISTAR
Input Voltage DC24V/
Protection Class IEC III
Control DMX / ON-OFF DMX DMX
Finish Rough  black
Housing High strength engineering PC
Cover High strength optical PC
IP Rating IP65
IK Rating IK10
Mounting Buckcle
Operation Temperature -35°C ~ 60°C (-31°F ~ 140°F)
Storage Temperature -40°C ~ 70°C (-40°F ~ 158°F)
Lifespan >50,000Hrs (Ta=35°C@L70)
Certificate CE / RoHS / EMC

■ Please contact our sales team for more product details.
■ Archillumi work on global lighting market. Products can be customized based on special requirement.
